DVB-S2 |
Input Frequency:950~2150MHz Loop Out Frequency:950~2150MHz Input Level:-65~-25dBm Input Impedance:75¦¸ LNB Power: Auto/14v/18v/OFF, Imax = 500mA |
|
Video decoder |
Video Compression MPEG-2 and MPEG-1 compatible, H.246 Video Formats 4:3 / 16:9 Letterbox for 4:3 TV-Device |
|
Audio decoder |
Audio Compression MPEG-1 & MPEG-2 Layer I and II, MP3 Audio Mode Dual (main/sub), Stereo Frequency: 32 kHz, 44.1 kHz, 48 kHz, 16 kHz, 22.05 kHz, 24 kHz |
|
Output digital |
Output Level 0,5 Vss on 75 Ohm Sampled Data Filtering 32 kHz, 44.1 kHz, 48 kHz S/PDIF-Output optical, Toslink |
|
Video parameter |
Input Level FBAS 1 Vss +/- 0.3 dB on 75 Ohm Teletext filter in conformity with ETS 300 472 Standard |
|
TV-Scart |
Output: FBAS, RGB, S-Video |
|
Serielle Interface RS 232 |
Typ RS232 bidirectional Bit rate 115,2 kBit/s max. Plug Connector SUB-D-9 Function: Update of Firmware |
|
Ethernet |
10/100 MBit compatible interface Function: Update of Firmware |
|
USB |
1 x USB 2.0 Host ,PVR |
|
LNB power and polarisation per tuner |
LNB Current 500mA max.; short-circuit-protected LNB Voltage vertical < 14V no load, > 11,5V at 400mA LNB Voltage horizontal < 20V no load, > 17,3V at 400mA |
|
Count of active satellite position |
DiSEqC 1.0/1.1/unicable/1.2 SAT POSITION / SAT OPTION DiSEqC - Rotor Control |
|
External PSU |
Input:110-240V AC / 50-60Hz / 0,6A Output: 12V = / 3,0A |
|
Physical specification |
Ambient Temperature +15 °C...+35 °C Humidity < 80% Size (W x D x H): 300 mm x 220 mm x 56 mm Weight: 1,8 kg without HDD |
|
Power |
AC input range:100-240VAC 50/60Hz Power Consumption (Standby): Max. 10W (<1 W) |


(1) 兼容大容量录像,USB接插移动硬盘,U盘.(硬盘格式ntfs fat32)
(2) 省略。。。
(3) 除具有一般视频AV.S端子输出方式外,还具有高清HDMI输出,
(4) 省略。。。
(5) 省略。。。
(6) LED显示机器状态,
(7) 支持MP2 MP4解码,兼容S,S2目前高清信号格式
(8) USB软件升级,信息导入,提供软件支持更新
(9) MP3播放功能.支持S.S2信号盲扫功能
(10) 节目信息可编辑,可将节目备份到U盘,自行修改
全民高清时代已经到来!可完全取代DM系列,成为S2主流的高清与标清的收视平台!
直接设置好发货,客户收到即可直接使用!
强大的技术支持后盾!一年质量保修!
|
